Grinding Spindles Home > Product > Grinding Spindles


SW110-1255-S

본문

Edge grinding or multi grinding spindles

SW110-1255-T
Edge grinding
SW110-1255-TT
Edge grinding
SW110-1255-S
Edge grinding
SW110-1255-H40C
Edge grinding

Specification
Sortation SW110-1255-T SW110-1255-TT SW110-1255-S SW110-1255-H40C
Housing diameter(Ø) 110 110 110 110
Housing material Stainless steel Stainless steel Stainless steel Stainless steel
Power(S1)kw 5.5 5.5 5.5 5.5
Speed(rpm) 12,000 12,000 12,000 12,000
Frequency(Hz) 400 400 400 400
Torque(Nm) 4.5 4.5 4.5 4.5
Current(A) 26.26 26.26 26.26 26.26
Motor poles 4 4 4 4
Tool change manual manual manual manual
Tool interface taper taper straigt HSK C40
option × flange, front and rear rotary joint flange flange
Cooling system water / oil water / oil water / oil water / oil
Bearing lubrication grease grease grease grease
Weight(kg) 18 20 18 18

Floor plan
